Dell PowerEdge R740 2U 2 Socket Rackmount Server

The PowerEdge R740 rack server was designed to accelerate application performance leveraging accelerator cards and storage scalability. The 2-socket, 2U platform has the optimum balance of resources to power the most demanding environments.

Dell PowerEdge R740 1U Rack Server Technical Specifications

Form factor

       Rack (2U)

Processor

       Up to two 2nd Generation Intel® Xeon® Scalable processors, up to 28 cores per processor

Memory

       24 DDR4 DIMM slots, Supports RDIMM /LRDIMM, speeds up to 2933MT/s, 3TB max
       Up to 12 NVDIMM, 192 GB Max

       Up to 12 Intel® Optane™ DC persistent memory PMem, 6.14TB max (7.68TB max with   PMem + LRDIMM) Supports registered ECC DDR4 DIMMs only

Storage

       Front drive bays: Up to 16 x 2.5” SAS/SATA (HDD/SSD) max 122.88TB or up to 8 x 3.5”      SAS/SATA HDD max 128TB

       Optional DVD-ROM, DVD+RW

GPU Options

       Up to three 300W or six 150W GPUs,

       Or up to three double-width or four single-width FPGAs.

Dimensions

       Height: 86.8mm (3.4”)

       Width: 434.0mm (17.08”)

       Depth: 737.5mm (29.03”)

       Weight: 28.6kg (63lbs.)
